Product Details:
|
| Channels: | 8 | Direct Sensor Input: | J, K, T, E, R, S, B Thermocouple |
|---|---|---|---|
| Sampling Rates: | 10 Samples/second | Resolution: | 16-bit |
| Power Requirement: | 10~30 VDC | Interface: | RS-485 |
| Temperature (Operating): | -10~70 °C (14~158 °F) | Temperature (Storage): | -25~85 °C (-13~185 °F) |
| High Light: | 15 mA Thermocouple Input Module,RS 485 Thermocouple Input Module,RS 485 usb DAQ module |
||
8-channel Thermocouple Input Module
Product Introduction
Sl4018 + is a 16 bit, 8-Channel analog input module with programmable input range. These modules are an economical solution for industrial measurement and monitoring applications. It can provide 3000vdc optical isolation protection between analog input channel and module to avoid damage of module and peripheral equipment by high voltage on input line.
Main Features
Analog Input
|
Channels
|
8 differential
|
| Current Input |
±20 mA, 4~20mA
|
| Direct Sensor Input |
J, K, T, E, R, S, B Thermocouple
|
| Burn-out Detection |
Yes (All T/C)
|
| Channel Independent Configuration |
Yes
|
| Sampling Rates |
10 samples/second
|
| Resolution |
16-bit
|
| Input Impedance |
Thermocouple: 20 MOhm Current: 120 Ohm
|
| Span Drift |
±25 ppm/°C
|
| Zero Drift |
±6 µV/°C
|
General
|
Watchdog Timer
|
System (1.6 second) & Communication
|
| Connector |
2 x plug-in terminal block (#14~22 AWG)
|
| Temperature (Operating) |
-10~70 °C (14~158 °F)
|
| Humidity |
5~95 %RH
|
| Temperature (Storage) |
-25~85 °C (-13~185 °F)
|
| Interface |
RS-485
|
| Isolation Protection |
3000 VDC
|
| Communication Protocol |
ASCII command & Modbus/RTU
|
| Communication Speed |
Serial: From 1,200 to 115.2 k
|
| Comm. Distance |
Serial: 1.2 km
|
| Data Flow Control |
Yes
|
