SeeLong 6000 Rpm 0.2%FS Torque Dynamometer

SeeLong 6000 Rpm 0.2%FS Torque Dynamometer
SeeLong 6000 Rpm 0.2%FS Torque Dynamometer

Large Image :  SeeLong 6000 Rpm 0.2%FS Torque Dynamometer

Product Details:
Place of Origin: China Luoyang
Brand Name: SeeLong
Certification: CMC
Model Number: SMMC-75/6000
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 32500dollar
Packaging Details: 1500mmF*1000mm*2000mm wooden box
Delivery Time: 10-12weeks
Payment Terms: T/T
Supply Ability: 10 sets per month

SeeLong 6000 Rpm 0.2%FS Torque Dynamometer

Description
Power: 75KW Torque Range: 472Nm
Speed Range: 5000rpm Torque Accuracy: 0.2%FS
Speed Accuracy: 0.1r/min Rated Voltage: 380V±10% 50Hz
Service Temperature: -20to45℃ Use Altitude: <2000m
High Light:

0.2%FS Torque Dynamometer

,

6000 rpm Torque Dynamometer

,

6000 rpm dynamometer torque measurement

SMMC 75--110KW 6000rpm 0.2%FS High Torque Dynamometer



Applications



SMMC is the economic model of SMYC, and its function is the same as SMYC; the measurement accuracy of SMMC power dynamometer is ± 0.2% FS, which is slightly lower than SMYC.



SMMC Series dynamometer is a special test equipment with low speed and high torque.



Its main purpose is to test the performance of commercial vehicle engine, bus engine and marine engine. These samples have the characteristics of low speed and high torque output. SMMC realizes the accurate control of speed and torque through the efficient inverter system, and all test operations can be completed by computer control commands. At the same time, the high-speed data communication module makes the system have high real-time performance. SMMC Series dynamometer has the characteristics of small volume, small moment of inertia, zero speed torque output and high dynamic response.



Technical Features



  • High torque output at low speed
  • Measurement accuracy: speed ± 0.1 R / min; torque ± 0.05% FS
  • At zero speed, the full load can be added, and the speed can be reduced to zero without torque attenuation, which can reach twice the full load in a short time.
  • Excellent loading performance: constant torque loading can be maintained from zero speed to rated speed, and constant power loading can be maintained above rated speed.
  • Low moment of inertia and high overload capacity make the dynamometer have high dynamic response speed, the dynamic response speed is less than 5ms



Characteristic



  • Energy saving: The mechanical energy generated by the prime mover is converted into electrical energy and fed back to the internal power grid for use by other equipment.



  • Loading mode: It can provide two-way consistent loading capacity, which can still provide enough loading capacity when the speed reaches 0r / min; the loading characteristic is constant torque characteristic from zero speed to rated speed, and constant power optimization rate characteristic from rated speed to maximum speed. In order to adapt to different steering power mechanical test.



  • Transient loading characteristics: The main response time of the dynamometer is ms level.



  • Towing capacity: The electric dynamometer can be easily converted into motor driving mode, absorb energy from the power grid, and be used as the power mechanical reverse towing prime mover.





Specifications (Can be customized)



Model Power(KW) Torque(Nm) Rated Speed(rpm) Max Speed(rpm) Torque Measurement Accuracy
SMMC75 75 531 1350 5000 0.2%FS
SMMC90 90 637 1350 5000 0.2%FS
SMMC100 100 707 1350 5000 0.2%FS
SMMC110 110 778 1350 5000 0.2%FS
Can be customized




FAQ



Q:What’s the minimum order quantity for our cooperation?

A: We support small trail order of 1 pcs for stock products.

Q: How can I learn more about the products?

A: Please leave your email and we will send you your electronic sample book.

Q: What’s your payment term?

A: Normally 30% T/T deposit, pay in full before shipment.

Q:What’s the lead time for my orders?

A: Dynamometers production cycle is 6-8 weeks, sensors prodction cycle is 2-3 weeks, other products please contact with us.

Q: How do we get the overall solution of the test bench?

A: Leave us your email, our technical staff will communicate with you about the detailed plan.

Q:Can I come to visit your factory?

A: Sure, you are always welcome to have a visit.
