Product Details:
|
| Power: | 60KW | Rated Torque: | 382Nm |
|---|---|---|---|
| Max Working Speed: | 5000rpm | Constant Power Range: | 1500--5000rpm |
| Constant Torque Range: | 0-1500rpm | Measurement Accuracy: | 0.05/0.2/0.5 |
| High Light: | 0.05% Accuracy AC Dynamometer,382Nm AC Dynamometer,60KW AC Dynamometer |
||
Low Power High Accuracy 60KW 382Nm Electric Motor Drive Dynamometer
Introduction
The electric dynamometer has been widely used with the application of power electronic technology, sensors, computers and control technology. Compared with other types of dynamometers, the electric dynamometer can not only achieve energy feedback, but be used as a motor to drive DUT rotate. Early electric dynamometers are DC type, DC motors have goodspeed and the control technology is simple and mature. However, DC electric dynamometers are not suitable for high speed applications due to the influence of commutator. As the DUT runs at high speed, a mechanical reducer is required for the DC electric dynamometer system, complex, high noise, high friction torque, affecting the accuracy of the measurement. AC asynchronous electric dynamometers have been widely used in recent years for its simple structure, wide measurement range and high accuracy.
Product feature
Can be used to verify performance to all government electric motor efficiency standards.
Offers overload capabilities, making it possible to size units for continuous power, rather than brief transient events. Seelong dynamometers typically offer overload capacities of 150 percent for 30-60 seconds and 200 percent for up to 3 seconds. Higher overload capacities are also available, as needed.
Characteristic curve
Application case
