Product Details:
|
| Measuring Range: | 1000N.m | Accuracy Class: | 0.2%FS |
|---|---|---|---|
| Working Speed: | 0-10000rpm | Overload Capacity: | 150% |
| Interface: | RS485/RS232 | Power Supply: | ±12V DC |
| Use Temperature: | - 20 ℃ - 50 ℃ | Signal Type: | 0-10VDC（Optional） |
| Highlight: | 1000Nm Digital Torque Meter,10000rpm Digital Torque Meter |
||
SLZN - 1000 Axis Dynamic Torque Sensor 1000N.m 0.2%FS High Speed Torque and Rotational Speed Measurer
SLZN Axis Torque Sensor 1000N.m 0.2%FS for Motor Engine Gearbox Test
Product introduction
Torque sensor based on resistance strain for sensitive components and integrated circuit products consisting of an organic whole, is the use of advanced production technology and advanced testing equipment and imported strain gauge, integrated the advantages of the torque sensor at home and abroad, to overcome the poor to a torque sensor of low speed measurement for the inconvenience and volume of large and bulky, and slip ring torque sensor can't long time continuous work inconvenience. This product adopts non-contact data transmission mode, is the use of wireless power supply and wireless output in the form of working principle, for dynamic torque measurement to solve the shortcomings of other ways of measuring dynamic torque.
Application
1.Testing the output torque and power of motor, engine, internal combustion engine and other rotating power equipment
2.Test the torque and power of fan, water pump, gear box and torsion plate
3.Railway locomotives, automobiles, tractors, aircraft, ships, mining machinery torque and power testing
4.Can be used in the sewage treatment system torque and power detection;
5.Can be used in the manufacture of viscometers
6.Can be used in process industry and process industry
7.Can be used in laboratories, testing departments and production monitoring and quality control
Technical parameters
| Item | Parameters |
| Model | SLZN |
| Torque range | 0±1000N.m(optional) |
| Torque output | 5-15KHZ,0±10V,0±5V,0-10V,4-20mA |
| Speed output | 60 pulse/r,4-20mA |
| Speed range | 0-20000 rpm/min |
| Measurement accuracy | 0.2% |
| Response frequency | 500μs |
| Supply voltage | 24VDC |
| Overload capacity | 150% |
| Zero drift | ＜0.5% |
| Environmental temperature | -40℃-80℃ |
| Relative humidity | ＜90%RH |
| Work amplitude | 10V |
| Surface treatment | Anodic treatment |
| Sensor material | alloy steel/stainless steel/aluminum |
| Sensor power consumption | 4W |
Product features:
● The internal use of unique non-contact mode wireless transmission torque signal output.
● With good stability, high precision, good reliability and long life.
● Can measure the dynamic torque, static torque; The output of torque signal has nothing to do with the speed, rotation and steering.
● No need to adjust the zero position repeatedly can continuously measure the positive and negative torque signal.
● Signal using digital technology, strong anti-interference.
● No collecting ring and other wear parts, can run for a long time at high speed
● Torque measurement accuracy is independent of rotation speed and direction.
Product Description
Outside view
Installation Instruction
Placement: Connection between torque sensor and power equipment and load equipment
