SLFN-2000 2000Nm 0.2%FS Flange Torque Sensor For Engine

SLFN-2000 2000Nm  0.2%FS Flange Torque Sensor For  Engine
SLFN-2000 2000Nm  0.2%FS Flange Torque Sensor For  Engine SLFN-2000 2000Nm  0.2%FS Flange Torque Sensor For  Engine

Large Image :  SLFN-2000 2000Nm 0.2%FS Flange Torque Sensor For Engine

Product Details:
Place of Origin: China Luoyang
Brand Name: SeeLong
Certification: CMC
Model Number: SLFN-2000
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiated
Packaging Details: 1500mmF*1000mm*2000mm wooden box
Delivery Time: 10-15days
Payment Terms: T/T
Supply Ability: 20 pcs per month

SLFN-2000 2000Nm 0.2%FS Flange Torque Sensor For Engine

Description
Measuring Range: 2000Nm Accuracy Class: 0.2%
Working Speed: 0-10000rpm Overload Capacity: 120%
Response Frequency: 500 μ S Lag: <0.1%
Relative Humidity: <90%RH Temperature Range: -10-70℃
High Light:

2000Nm Flange Torque Sensor

,

CMC Engine Flange Torque Sensor

SLFN-2000 2000Nm 0.2%FS Flange Torque Sensor For Engine



SLFN 200Nm 0-10000rpm 0.2%FS economical torque flange for engine





Torque sensors



Flanged torque sensors have the characteristics of conventional torque sensors, but also have a system self-detection function, when used in torque measurement, this feature has a huge advantage.
The small axial dimension of the flange torque sensor is a great advantage, allowing it to be used in a wide variety of measuring environments and in a wide variety of measured components.





Product features



  1. Thin, bearing free, high precision, firm

  2. High precision, optional frequency or voltage signal output

  3. The axial dimension is very small

  4. Compact flange-flange connection design

  5. Digital non-contact signal transmission

  6. Bearing less, no maintenance required

  7. System self - check function





Technical parameter





Measuring range

0±50N.m ±100N.m ±200N.m ±500N.m ±1000N.m

±2000N.m ±5000N.m ±1 万 N.m

Output signal

5-15KHZ 0-10V 4-20mA

Overload capacity

120%

Accuracy

0.5% 0.2%

Power supply

24VDC

Optimum operating Speed

0-15000 rpm



Response frequency



500μs

Insulation resistance

>200MΩ

Zero drift



<0.5%

Repetitive

<0.1%

Linear

<0.1%

Lag

<0.1%

Environment temperature

-40-60℃

Relative humidity

<90%RH

Temperature range

-10-70℃

Amplitude of transmitter

10V

Storage temperature range

-25-80℃

Transducer power consumption

≈4W

Sensor current consumption

100MA

Sensor shell



Strong anodized aluminum

The response time of the strain gauge dynamic strain wave

3.2X10-6s





Layout



SLFN-2000 2000Nm  0.2%FS Flange Torque Sensor For  Engine 0





product picture



SLFN-2000 2000Nm  0.2%FS Flange Torque Sensor For  Engine 1





FAQ



Q:What’s the minimum order quantity for our cooperation?

A: We support small trail order of 1 pcs for stock products.

Q: How can I learn more about the products?

A: Please leave your email and we will send you your electronic sample book.

Q: What’s your payment term?

A: Normally 30% T/T deposit, pay in full before shipment.

Q:What’s the lead time for my orders?

A: Dynamometers production cycle is 6-8 weeks, sensors prodction cycle is 2-3 weeks, other products please contact with us.

Q: How do we get the overall solution of the test bench?

A: Leave us your email, our technical staff will communicate with you about the detailed plan.

Q:Can I come to visit your factory?

A: Sure, you are always welcome to have a visit.
