SLZN-200 Seelong Self-Manufactured Shaft Torque Sensor 200n. M 0.2%Fs for Transmission Test

SLZN-200 Seelong Self-Manufactured Shaft Torque Sensor 200n. M 0.2%Fs for Transmission Test
SLZN-200 Seelong Self-Manufactured Shaft Torque Sensor 200n. M 0.2%Fs for Transmission Test SLZN-200 Seelong Self-Manufactured Shaft Torque Sensor 200n. M 0.2%Fs for Transmission Test SLZN-200 Seelong Self-Manufactured Shaft Torque Sensor 200n. M 0.2%Fs for Transmission Test SLZN-200 Seelong Self-Manufactured Shaft Torque Sensor 200n. M 0.2%Fs for Transmission Test SLZN-200 Seelong Self-Manufactured Shaft Torque Sensor 200n. M 0.2%Fs for Transmission Test SLZN-200 Seelong Self-Manufactured Shaft Torque Sensor 200n. M 0.2%Fs for Transmission Test

Large Image :  SLZN-200 Seelong Self-Manufactured Shaft Torque Sensor 200n. M 0.2%Fs for Transmission Test

Product Details:
Place of Origin: China
Brand Name: Seelong
Certification: CMC
Model Number: SLZN-200
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiated
Packaging Details: Seaworthy Plywood
Delivery Time: 90 working days
Supply Ability: 30 pcs per month

SLZN-200 Seelong Self-Manufactured Shaft Torque Sensor 200n. M 0.2%Fs for Transmission Test

Description
Rated Torque: 200 Working Speed Rpm: 10000
Max Working Speed Rpm: 35000 Measurement Accuracy: 0.2%FS
Speed Measurement: 60 Pulse/rpm

SLZN-200 Seelong Self-manufactured Shaft Torque Sensor 200N.M 0.2%FS For Transmission Test

Product description

Slzn-200 dynamic torque sensor is a non-contact high-speed rotation sensor, also known as torque speed sensor, because of its high measurement quality and low linear error, sensor has been in the advantage of torque measurement products. The SLZN-200 torque sensor adopts a non-contact design and is suitable for long time rotational torque measurement and high speed rotational torque measurement environments due to the absence of wearing parts. The SLZN-200 torque sensor is a good choice for testing systems on production lines or test stands or on test machines.



Product features

1. The power supply and signal transmission are non-contact.

2. No bearing, wide range of speed.

3. The connection with power shaft and load shaft is rigid connection.

4. It is convenient to install and debug. The radial runout of the user's shaft is less than 0.05mm, and the axial movement is less than 0.5mm. The adjusting bolt at the bottom of the sensor can easily adjust the installation clearance.

5. This model has two kinds of output with 485 bus and without 485 bus: standard type without 485 port; bus type with 485 port, USB data line of computer and measurement software of upper computer.

6. This model of products are dynamic balance before delivery, suitable for high speed.

SLZN-200 Seelong Self-Manufactured Shaft Torque Sensor 200n. M 0.2%Fs for Transmission Test 0

Product characteristics

  • Built in digital measurement signal conditioning unit, through contactless transmission, the data is directly output in standard analog or digital signal mode
  • Strong anti-interference ability
  • The rotor rotates in the stator ring, no mechanical bearing is allowed, so there is no wear.
  • 0.5 or 0.1 precision level, optional current, voltage or frequency signal output
  • High precision magnetoelectric angle / speed measuring unit, dust and moisture proof
  • Parameter identification, setting, measurement and zero balance of sensor are realized through RS-485 interface
  • Very small axial size compact flange flange connection design
  • Digital non-contact signal transmission, no bearing, no maintenance, system self-test function



SLZN-200 Seelong Self-Manufactured Shaft Torque Sensor 200n. M 0.2%Fs for Transmission Test 1



Why choose us

After years of development and accumulation, the company has become a well-known powertrain test equipment production enterprises. Specializing in engine test, transmission test, energy storage test, controls and electric motor test and other test equipment research, development and production service. The company has established long-term cooperation with tsinghua university, Shandong university and many other domestic scientific institutions. We have successfully passed the ISO9001 Quality System certification, obtained a dozen of invention patents and two software copyrights. We have provided professional services and equipment for more than 100 users at home and abroad and which is ongoing now and will continue in the future.
